ENPHASE MICRO INVERTERS
Avoid bulky inverters in your home by using Enphase solar micro inverters
Inquire Now


Select Model:
S230
S270
Enphase S230
Built on the fifth-generation platform, the Enphase S230 Micro Inverter achieves the highest inverter efficiency for module-level power electronics. With its all-AC approach, the S230 simplifies design and installation, and delivers optimal energy harvest. The S230 is compatible with storage systems, including battery management systems.
Enphase S270
Built on the fifth-generation platform, the Enphase S270 Micro Inverter achieves the highest inverter efficiency for module-level power electronics for both 60-cell and high-powered 72-cell modules. With its all-AC approach, the S270 simplifies design and installation, and delivers the most reliable energy solution for your customers.
S230 Micro InverterSee More
Maximum Input DC Voltage: | 48 V |
---|---|
Operating Range: | 16 – 48 V |
Peak Output Power: | 230 VA |
Nominal Output Current: | 0.95 A |
Nominal Voltage: | 230 V |
Nominal Frequency: | 50 Hz |
Peak Efficiency: | 96.7% |
Ambient Temp. Range: | -40ºC to +65ºC |
Protection Category: | IP 67 |
Dimensions: | 172 x 175 x 35 mm |
Weight: | 1.8 kg |
S270 Micro InverterSee More
Maximum Input DC Voltage: | 60 V |
---|---|
Operating Range: | 16 – 48 V |
Peak Output Power: | 270 VA |
Nominal Output Current: | 1.15 A |
Nominal Voltage: | 230 V |
Nominal Frequency: | 50 Hz |
Peak Efficiency: | 96.9% |
Ambient Temp. Range: | -40ºC to +65ºC |
Protection Category: | IP 67 |
Dimensions: | 172 x 175 x 35 mm |
Weight: | 1.8 kg |
STAY CONNECTED With Enphase Envoy

The Envoy collects real-time data from your micro inverters and delivers remote updates back out to them, keeping your entire system in constant communication. Meaning not only do you have information and insights about your solar system while you’re out and about, you can even resolve issues remotely.
Monitoring your solar power system has never been this easy.
Monitoring your solar power system has never been this easy.
Envoy

Envoy-S Standard

Envoy-S Metered

Inquire Now!
OPTIONALLY
Enphase AC Battery
The Enphase Battery is a high-performance energy storage system, bringing you intelligence and great value. It pairs seamlessly with Enphase micro inverters and other solar technologies to help you make the most of your energy.
Enphase BatterySee More
Capacity: | 1.2 kWh |
---|---|
Depth of Discharge: | 100% |
Peak Output Power: | 270 VA |
Power Factor: | 0.7 leading to 0.7 lagging |
Rated (Cont.) Output Power: | 260 VA |
Nominal Frequency: | 50 Hz |
Roundtrip Cell Efficiency: | 96% |
Ambient Temp. Range: | -20ºC to 45ºC |
Protection Category: | IP 20 |
Dimensions: | 390 x 325 x 220 mm |
Weight: | 25 kg |

Inquire Now!
