ENPHASE MICRO INVERTERS

Avoid bulky inverters in your home by using Enphase solar micro inverters

Inquire Now
Enphase S230 Micro InverterEnphase S230 Micro Inverter
Select Model:

S230
S270

Enphase S230

Built on the fifth-generation platform, the Enphase S230 Micro Inverter achieves the highest inverter efficiency for module-level power electronics. With its all-AC approach, the S230 simplifies design and installation, and delivers optimal energy harvest. The S230 is compatible with storage systems, including battery management systems.

Enphase S270

Built on the fifth-generation platform, the Enphase S270 Micro Inverter achieves the highest inverter efficiency for module-level power electronics for both 60-cell and high-powered 72-cell modules. With its all-AC approach, the S270 simplifies design and installation, and delivers the most reliable energy solution for your customers.
S230 Micro InverterSee More
Maximum Input DC Voltage: 48 V
Operating Range: 16 – 48 V
Peak Output Power: 230 VA
Nominal Output Current: 0.95 A
Nominal Voltage: 230 V
Nominal Frequency: 50 Hz
Peak Efficiency: 96.7%
Ambient Temp. Range: -40ºC to +65ºC
Protection Category: IP 67
Dimensions: 172 x 175 x 35 mm
Weight: 1.8 kg
S270 Micro InverterSee More
Maximum Input DC Voltage: 60 V
Operating Range: 16 – 48 V
Peak Output Power: 270 VA
Nominal Output Current: 1.15 A
Nominal Voltage: 230 V
Nominal Frequency: 50 Hz
Peak Efficiency: 96.9%
Ambient Temp. Range: -40ºC to +65ºC
Protection Category: IP 67
Dimensions: 172 x 175 x 35 mm
Weight: 1.8 kg

STAY CONNECTED With Enphase Envoy

wireless
The Envoy collects real-time data from your micro inverters and delivers remote updates back out to them, keeping your entire system in constant communication. Meaning not only do you have information and insights about your solar system while you’re out and about, you can even resolve issues remotely.
Monitoring your solar power system has never been this easy.
Envoy
enphase envoy
Envoy-S Standard
enphase envoy-s standard
Envoy-S Metered
enphase envoy-s metered
Inquire Now!
OPTIONALLY

Enphase AC Battery

The Enphase Battery is a high-performance energy storage system, bringing you intelligence and great value. It pairs seamlessly with Enphase micro inverters and other solar technologies to help you make the most of your energy.
Enphase BatterySee More
Capacity: 1.2 kWh
Depth of Discharge: 100%
Peak Output Power: 270 VA
Power Factor: 0.7 leading to 0.7 lagging
Rated (Cont.) Output Power: 260 VA
Nominal Frequency: 50 Hz
Roundtrip Cell Efficiency: 96%
Ambient Temp. Range: -20ºC to 45ºC
Protection Category: IP 20
Dimensions: 390 x 325 x 220 mm
Weight: 25 kg
Enphase AC Battery
Inquire Now!
